PCB Assembly Services
Full turnkey, partial turnkey, and consigned PCB assembly, from single prototypes to full production runs.
- Surface-mount, through-hole, and mixed-technology assembly down to 0201 components and 12-mil pitch
- AOI and 3D X-ray inspection, plus in-circuit and functional testing, in-house
- Standard production in 4–5 weeks, with expedited builds available
Request a PCB assembly quote
Attach your Gerber files, BOM, and PCB specifications for a firm quote and lead time.
No file package yet? A short project description is enough for a ballpark estimate.
- ISO 9001:2015 certified
- ITAR registered
- IPC-A-610 inspection
- Assembled in the USA
- No minimum order
Capabilities
Assembly, inspection, and test in‑house
All assembly, inspection, and testing is performed on our own Panasonic SMT lines and test equipment.
| Technology | SMT, through-hole, and mixed technology; single- and double-sided; rigid, flex, and rigid-flex |
|---|---|
| Components | 0201 passives, fine-pitch ICs to 12-mil pitch, BGA, micro-BGA, QFN |
| Inspection | AOI on every board, 3D X-ray on every BGA, final visual inspection to IPC-A-610 |
| Test | In-circuit (fixtured and fixtureless) and functional testing to your test plan |
| Solder process | Lead-free (RoHS-compliant) and leaded, with separate paste profiles, ovens, and process controls |
| Board size | Up to 20 × 18 in (510 × 460 mm); small boards assembled in panels |
| Layers | 1–24 layers, rigid and flex; bare boards sourced to your fabrication drawing |
| Protection | Conformal coating and potting |
|---|---|
| Procurement | Full turnkey, partial turnkey, or consigned |
| Volumes | Prototype, low-volume, and production; JIT and Kanban programs |
| Lead time | Standard production 4–5 weeks, confirmed with your quote |
| Expedite | Available on request; priced in your quote |
| Industries | Industrial, medical, automotive, telecommunications, LED lighting, RF/IoT, and consumer electronics |
Process
From quote to delivery
- 1File reviewWe review your files and request anything missing.
- 2DFM and pricingYour quote includes a firm lead time and any manufacturability issues we identify.
- 3PO and procurementWe purchase components (turnkey) or receive your kit (consigned).
- 4Build and inspectionWe assemble and inspect to IPC-A-610 and your specifications.
- 5Test and shipmentWe test to your test plan, then package and ship.
Quality
ISO 9001:2015 certified, ITAR registered
Our quality management system is certified to ISO 9001:2015 by Perry Johnson Registrars (ANAB accredited) for the contract manufacture of printed circuit board assemblies. Final inspection follows IPC-A-610. View certificate →
As an ITAR-registered manufacturer, we keep controlled work on site and document it in accordance with ITAR requirements.
“I have been dealing with Absolute Electronics for the past 4 years. I recently utilized their Illinois location for a rush order. Everything went smoothly and without issues. I am very pleased with the work of Absolute Electronics and will continue to use them as an important part of my business.”
Industrial electronics manufacturer
“Absolute Electronics handled my expedited PCB assembly request perfectly. The entire process was smooth from start to finish, and the final assembly was exactly what I needed. I couldn’t have asked for a better experience and highly recommend working with them.”
Consumer electronics manufacturer
“Great experience overall with excellent and reliable service. Everything was handled smoothly and met my expectations perfectly. The staff was helpful and professional throughout. I’m very satisfied and would definitely recommend it to others.”
Telecom manufacturer
Questions
Frequently asked questions
For questions specific to your project, email our sales team or call (224) 366-0290.
Is there a minimum order quantity?
No. We build everything from a single prototype to full production runs.
What files do I need for a quote?
For a firm quote, send Gerber files, a BOM, and PCB specifications. For a ballpark estimate, a description of the board size, layer count, and approximate component count is enough.
What are your lead times?
Standard production lead time is 4–5 weeks and is confirmed with your quote. Quick-turn prototypes typically ship within 3–5 business days, and expedited production is available on request.
Do you support lead-free and leaded assembly?
Yes. Lead-free (RoHS-compliant) and leaded assemblies run with separate paste profiles, ovens, and process controls.
Can you build ITAR-controlled assemblies?
Yes. We are ITAR registered. Controlled work remains in our Addison, Illinois, facility and is documented in accordance with ITAR requirements.
What happens when I move from prototype to production?
Build documentation, DFM notes, and inspection records carry forward. Production runs on the same line, so no requalification is needed unless the design changes significantly.
Get a quote for your next build
Send your files for a quote, or call to discuss your project first.
